Domestic fan aRid
aRid is an axial celling fan. Its design was inspired by an air turbine. Long engine life is guaranteed thanks to the highest quality ball-bearing.
Ø 100 Ø 120 Ø 150
Available models:
The fan turns on when power is applied (e.g., on a switch shared with the light) and will work until the power is turned off plus for the time set on the controller. This works well, for example, after a bath, where moisture is still blown out after the user leaves the bathroom.
The fan requires a three-wire cable, as it is necessary to connect the control cable.
Has a humidity sensor, which the user sets in the range of 40 – 80%. The fan turns on when the set threshold is exceeded by bounds (e.g., when taking a bath) and runs until the humidity level is lowered plus about 3 minutes – to maintain the effect.
The fan requires a three-wire cable, as it is necessary to connect the control cable.
The aRid fan, designed for ceiling installation, features excellent ball bearing. High-quality materials ensure the device’s durability and maintain its aesthetic appeal. Our aRid fans are circular in shape, allowing them to blend neutrally with furniture and lighting. The well-shaped turbine blades provide quiet and economical operation.
All of our fans come with thermal protection, which safeguards against overheating. A back valve can be added to the fan to prevent reverse air flow.
size | code | version | air flow | acoustic pressure | static pressure | volatage frequency | motor power | rev.(1/min) | protection degree | net weight | gross weight | pcs in a package |
---|---|---|---|---|---|---|---|---|---|---|---|---|
100 |
01-040 01-041 01-042 |
BB S BB TS BB HS+TS |
104 m3/h | 1m 39dB 3m 38dB | do 30 Pa | 220-230V/ 50-60Hz | 15 W | 2400+-200 | IP X4 | PS 0,54 kg S/TS/HS ~ 0,45 kg | PS 0,63 kg S/TS/HS ~ 0,55 kg | 20 |
120 |
01-043 01-044 01-045 |
BB S BB TS BB HS+TS |
158 m3/h | 1m 46dB 3m 44dB | do 30 Pa | 220-230V/ 50-60Hz | 16 W | 2200+-200 | IP X4 | PS 0,64 kg S/TS/HS ~ 0,57 kg | PS 0,74 kg S/TS/HS ~ 0,66 kg | 20 |
150 |
01-046 01-047 01-048 |
BB S BB TS BB HS+TS |
257 m3/h | 1m 47dB 3m 45dB | do 20 Pa | 220-230V/ 50-60Hz | 20 W | 1450+-200 | IP X4 | PS 0,77 kg S/TS/HS ~ 0,70 kg | PS 0,88 kg S/TS/HS ~ 0,80 kg | 10 |
[mm] | aRid ø 100 | aRid ø 120 | aRid ø 150 |
---|---|---|---|
A | 148 | 166,5 | 197 |
B | 107,5 | 107,5 | 107,5 |
C | 100 | 120 | 150 |
D | 85 | 85 | 85 |
