Industrial fan aRos

The wall-mounted fan is designed for use in commercial and industrial spaces.

* special order olny

Description

Models and technical specifications

Connection

Documents

Description

Models and technical specifications

size	code	air flow	acoustic pressure	static pressure	frequency voltage	motor power	rev. (1/min)	power consumption	max work temperature	net weight	degree of protection	insulation class
200	01-122	780 m3/h	52 db	140 Pa	220 V/50V, 50Hz	55 W	2500	0.25 A	60°C	2.5 kg	IP54	1
250	01-123	1450 m3/h	60 db	160 Pa	220 V/50V, 50Hz	90 W	2650	0.42 A	60°C	3.0 kg	IP54	1
300	01-124	2370 m3/h	62 db	150 Pa	220 V/50V, 50Hz	130 W	2480	0.6 A	60°C	4.0 kg	IP54	1
350	01-125	2450 m3/h	64 db	140 Pa	220 V/50V, 50Hz	129 W	1400	0,65 A	60°C	5,5 kg	IP54	1
400	01-126	3955 m3/h	67 db	200 Pa	220 V/50V, 50Hz	180 W	1380	0,82 A	60°C	6,5 kg	IP54	1
450	01-127	5000 m3/h	69 db	240Pa	220 V/50V, 50Hz	250 W	1350	1,15 A	60°C	8,0 kg	IP54	1
500	01-128	7155 m3/h	71 db	110 Pa	220 V/50V, 50Hz	380 W	1320	1,75 A	60°C	11,0 kg	IP54	1
550	01-129	8510 m3/h	72 db	110 Pa	220 V/50V, 50Hz	550 W	1300	2,55 A	60°C	11,0 kg	IP54	1
630	01-130	11143 m3/h	75 db	170 Pa	220 V/50V, 50Hz	750 W	1360	3,50 A	60°C	15,0 kg	IP54	1
*710	01-131	15120 m3/h	73 db	130 Pa	400 V/50V, 50Hz	900 W	900	1,90 A	60°C	30,0 kg	IP54	1
*800	01-132	20695 m3/h	75 db	170 Pa	400 V/50V, 50Hz	1200 W	920	2,80 A	60°C	35,0 kg	IP54	1

*The default version of aRos fans is the exhaust version. The supply version is available upon request.
