Industrial fan aRok

aRok fan is mounted in the walls. Used in utility rooms and industrial spaces.

* special order only

Description

Models and technical specifications

Documents

Connection

Description

Models and technical specifications

size	code	air flow	acoustic pressure	static pressure	voltage frequency	motor power	rev. (1/min)	power consumpion	max. work temperature	net weight	degree of protection	insulation class
200	01-111	780 m3/h	52 dB	140 Pa	220 V/50V, 50Hz	55 W	2500	0.25 A	60°C	3.0 kg	IP 54	F
250	01-112	1450 m3/h	60 dB	160 Pa	220 V/50V, 50Hz	80 W	2650	0.42 A	60°C	4.5 kg	IP 54	F
300	01-113	2330 m3/h	62 dB	220 Pa	220 V/50V, 50Hz	145 W	2480	0.60 A	60°C	6.0 kg	IP 54	F
350	01-114	2450 m3/h	64 dB	140Pa	220 V/50V, 50Hz	129 W	1400	0,65 A	60°C	7,0 kg	IP 54	F
400	01-115	3955 m3/h	67 dB	200 Pa	220 V/50V, 50Hz	180 W	1380	0,82 A	60°C	9,0 kg	IP 54	F
450	01-116	5000 m3/h	69 dB	240Pa	220 V/50V, 50Hz	250 W	1350	1,15 A	60°C	10 kg	IP 54	F
500	01-117	7155 m3/h	71 dB	110 Pa	220 V/50V, 50Hz	380 W	1320	1,85 A	60°C	14 kg	IP 54	F
550	01-118	8510 m3/h	72 dB	110 Pa	220 V/50V, 50Hz	550 W	1300	2,55 A	60°C	18 kg	IP 54	F
630	01-119	11143 m3/h	75 dB	170 Pa	220 V/50V, 50Hz	750 W	1360	3,50 A	60°C	24 kg	IP 54	F
*710	01-120	15120 m3/h	73 dB	130 Pa	400 V/50V, 50Hz	900 W	900	1,90 A	60°C	30 kg	IP 54	F
*800	01-121	20695 m3/h	75 dB	170 Pa	400 V/50V, 50Hz	1200 W	920	2,80 A	60°C	35 kg	IP 54	F

The default version of aRos fans is the exhaust version. The supply version is available upon request.
