Industrial fan aRd

aRd fan is a centrifugal fan used in duct mounting. Used in ventilation in ducts. Can be used in used in public places like shops, bars, restaurant’s, washing facilities as well as in houses, flats and industrial buildings ( garages, warehouses, storage halls).

Ø 100

Ø 125

Ø 150

Ø 160

Ø 200

Ø 250

Ø 315

Description

Models and technical specification

Documents

Description

Models and technical specification

size	code	air flow	acoustic pressure	frequency voltage	motor power	rev. (1/min)	net weight	max. work temp.	insulation class
100	01-133	250 m3/h	63 dB	230 V, 50 Hz	65 W	2600 r/min	3,5 kg	-25°C ~ +60°C	F
125	01-134	340 m3/h	68 dB	230 V, 50 Hz	68 W	2600 r/min	3,5 kg	-25°C ~ +60°C	F
150	01-135	590 m3/h	64 dB	230 V, 50 Hz	98 W	2500 r/min	4,5 kg	-25°C ~ +60°C	F
160	01-136	680 m3/h	65 dB	230 V, 50 Hz	100 W	2500 r/min	4,5 kg	-25°C ~ +60°C	F
200	01-137	970 m3/h	64 dB	230 V, 50 Hz	152 W	2550 r/min	6,1 kg	-25°C ~ +60°C	F
250	01-138	1050 m3/h	66 dB	230 V, 50 Hz	150 W	2550 r/min	6,1 kg	-25°C ~ +60°C	F
315	01-139	1440 m3/h	70 dB	230 V, 50 Hz	215 W	2550 r/min	6,8 kg	-25°C ~ +60°C	F
