Industrial fan aRos
aRos fan is mounted in the walls. Used in utility rooms and industrial spaces.
Ø 200
Ø 250
Ø 300
Ø 350
Ø 400
Ø 450
Ø 500*
Ø 550*
Ø 630*
Ø 710*
Ø 800*
Opis
Models
Technical specifications
Connection
Documents
Opis
aRos fans are designed for wall mounting and used in both commercial and industrial spaces. They feature a circular housing and are equipped with single-phase asynchronous motors with ball bearings. The motor is protected by a thermal fuse.
To optimize the device’s performance, you can use a speed controller. The fan housings are made of powder-coated steel sheet.
Models
| Size | Code |
|---|---|
| 200 | 01-122 |
| 250 | 01-123 |
| 300 | 01-124 |
| 350 | 01-125 |
| 400 | 01-126 |
| 450 | 01-127 |
| 500 | 01-128 |
| 550 | 01-129 |
| 630 | 01-119 |
| 710 | 01-130 |
| 800 | 01-131 |
Technical specifications
| size | code | air flow | acoustic pressure | static pressure | voltage frequency | motor power | rev.(1/min) | power consumption | max work temperature | net weight | degree of protection | insulation class |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
200 | 01-122 | 780 m3/h | 52 db | 140 Pa | 220 V/50V, 50Hz | 55 W | 2500 | 0,25 A | 60°C | 2,5 kg | IP54 | 1 |
| 250 | 01-123 | 1450 m3/h | 60 db | 160 Pa | 220 V/50V, 50Hz | 90 W | 2650 | 0,42 A | 60°C | 3,0 kg | IP54 | 1 |
300 | 01-124 | 2370 m3/h | 62 db | 150 Pa | 220 V/50V, 50Hz | 130 W | 2480 | 0,6 A | 60°C | 4,0 kg | IP54 | 1 |
| 350 | 01-125 | 2450 m3/h | 64 db | 140 Pa | 220 V/50V, 50Hz | 129 W | 1400 | 0,65 A | 60°C | 5,5 kg | IP54 | 1 |
400 | 01-126 | 3955 m3/h | 67 db | 200 Pa | 220 V/50V, 50Hz | 180 W | 1380 | 0,82 A | 60°C | 6,5 kg | IP54 | 1 |
| 450 | 01-127 | 5000 m3/h | 69 db | 240Pa | 220 V/50V, 50Hz | 250 W | 1350 | 1,15 A | 60°C | 8,0 kg | IP54 | 1 |
500 | 01-128 | 7155 m3/h | 71 db | 110 Pa | 220 V/50V, 50Hz | 380 W | 1320 | 1,75 A | 60°C | 11,0 kg | IP54 | 1 |
| 550 | 01-129 | 8510 m3/h | 72 db | 110 Pa | 220 V/50V, 50Hz | 550 W | 1300 | 2,55 A | 60°C | 11,0 kg | IP54 | 1 |
630 | 01-130 | 11143 m3/h | 75db | 170 Pa | 220 V/50V, 50Hz | 750 W | 1360 | 3,50 A | 60°C | 15,0 kg | IP54 | 1 |
| *710 | 01-131 | 15120 m3/h | 73 db | 130 Pa | 400 V/50V, 50Hz | 900 W | 900 | 1,90 A | 60°C | 30,0 kg | IP54 | 1 |
*800 | 01-132 | 20695 m3/h | 75 db | 170 Pa | 400 V/50V, 50Hz | 1200 W | 920 | 2,80 A | 60°C | 35,0 kg | IP54 | 1 |
*The default version of aRos fans is the exhaust version. The supply version is available upon request.
| [mm] | aRos ø 200 | aRos ø 250 | aRos ø 300 | aRos ø 350 | aRos ø 400 | aRos ø 450 | aRos ø 500 | aRos ø 550 | aRos ø 630 | aRos ø 710 | aRos ø 800 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| A | 203 | 260 | 310 | 360 | 410 | 460 | 500 | 560 | 630 | 703 | 784 |
| A1 | 223 | 278 | 325 | 376 | 426 | 474 | 530 | 580 | 662 | 703 | 784 |
| B | 284 | 320 | 400 | 460 | 525 | 600 | 567 | 635 | 705 | 770 | 857 |
| C | 73 | 78 | 85 | 95 | 110 | 125 | 250 | 250 | 250 | 253 | 253 |
| D | 252 | 295 | 380 | 442 | 504 | 578 | 542 | 606 | 675,5 | 840 | 920 |
Connection
Documents
Speed control
